ZC-300HHigh-Speed Extrusion Line for Double Wall Corrugated Pipe

Features of ZC-300H line

Pressure water-cooling for mould blocks greatly increase the production speed; the maximum speed is 10.3m/min.

Low energy consumption help to cut production cost.

Efficient vacuum system for forming perfect pipes.

Mould block temperature control system helps to optimize the pipe quality both appearance and inside.

Easy and quick changeover between different sizes of moulds.

The complete extrusion line runs full-automatically.

Corrugator and extruders are synchronously controlled.

Harden treated screw and barrels for longer life span and durability.

Remote Service is available.

Toolings (moulds) compatible to ZC-600H line and ZC-1000H line.

Field of application

Cable protection conduit for telecom cables and electricity cables.

Protection pipes for community heating systems.

Drainage pipes for streets, squares, golf course and sports field.

Storm water and sewage.

Main Technical Parameters

Pipe Range Min ID
Pipe Range Max OD
Installed gross capacity
Normal working power
Maximum production speed
Maximum Output
Overall dimension(L*W*H)

Composing of the extrusion line

Model SJPE-75/33B single screw extruder
1 set
Model SJPE-90/33B single screw extruder
1 set
Model ZC-300H high-speed water cooling corrugator
1 set
Model 300 spray cooling bath
1 set
Model 300 automatic sawdust-free cutting machine
1 set
Model 300 unloading device with weighing system
1 set

Based on the continuous optimization of product quality and performance, the product pictures and parameters involved in this page may be different from the real products. Zhongyun reserves the right to modify the appearance design and configuration parameters of the equipment without prior notice.
