Customized MouldsProduct

Mould blocks

The mould blocks are made of special aluminum alloy for high stiffness and high thermal-conductivity.

Mould block are compatible between different corrugator models. Production will be more flexible.

Easy and quick mould block change by fasten/loosen one screw only, to further reduce your downtime.

Direct water cooling mould blocks, cooling water circulate with pressure in a closed circuit.

The vacuum channel and water passage are designed with very wide flowing cross-section in order to ensure producing stably with high efficiency.

The mould blocks are manufactured by pressure casting for imporosity and higher stiffness.


We not only manfacture moulds and toolings for our own corrugated pipe extrusion lines,

but also supply die head and mould blocks to other corrugated pipe machines(such as corrugators

 made by European or North American companies), and achieve excellent result.

Customized Moulds


Not only regular customers of ZhongyunTech can order moulds from us, Anyone is welcomed to customize the moulds and enjoy professional designs & solutions from ZhongyunTech, no matter what kind of corrugated pipe machines you are using now.


You can customize new corrugation mould blocks, extrusion die head and calibrating mandrels from ZhongyunTech for your existing vertical or horizontal corrugated pipe machines. You will benefit from ZhongyunTech with the new mould by,


22 years experience in design and optimize corrugated pipe profiles, installed 700+ corrugated pipe machines in 36 countries. ZhongyunTech have helped lots of customer succeed in corrugated pipe business by superlative optimize to pipe profiles.

3 sets of production lines exclusively for corrugated pipe moulds manufacturing imported from Japan, ensure a stable quality of moulds with high manufacturing efficiency.

Highly accurate mould blocks manufactured by world-class CNC machines, such as Japanese TOSHIBA, DMG MORI flexible lines, Italy PAMA, Swiss +GF+ Mikron, Japan MAZAK, etc. Processing accuracy is 0.003mm.

And quality controlled by advanced European apparatus in constant temperature testing room, such as Sweden Hexagon advanced 3D coordinate measuring instrument, Lieca laser tracker, and Romer Absolute Arm. Inspecting accuracy is 0.0018mm.


*

Based on the continuous optimization of product quality and performance, the product pictures and parameters involved in this page may be different from the real products. Zhongyun reserves the right to modify the appearance design and configuration parameters of the equipment without prior notice.
