ZC-600H-Single/Double Wall Corrugated HDPE/PP Pipe Extrusion Line-ZhongyunTech

ZC-600HHigh-Speed Extrusion Line for Double Wall Corrugated Pipe

Features of ZC-600H line

Pressure water-cooling for mould blocks greatly increase the production speed; the maximum speed is 5.4m/min.

Low energy consumption help to cut production cost.

Efficient vacuum system for forming perfect pipes.

Mould block temperature control system helps to optimize the pipe quality both appearance and inside.

Easy and quick changeover between different sizes of moulds.

The complete extrusion line runs full-automatically.

Corrugator and extruders are synchronously controlled.

Harden treated screw and barrels for longer life span and durability.

Remote Service is available.

Toolings (moulds) compatible to ZC-300H line, ZC-1000H line and ZC-1200H.

Field of application

Cable protection conduit for telecom cables and electricity cables.

Protection pipes for community heating systems.

Drainage pipes for streets, squares, golf course and sports field.

Storm water and sewage.

Main Technical Parameters

Pipe Range Min ID
100mm
Pipe Range Max OD
630mm
Installed gross capacity
512kw
Normal working power
310kw
Maximum production speed
5.4m/min
Maximum Output
1150kg/hr
Overall dimension(L*W*H)
35m×5.5m×3.8m

Composing of the extrusion line

Model SJPE-90/33B single screw extruder
1 set
Model SJPE-120/33B single screw extruder
1 set
Model ZC-600H high-speed water cooling corrugator
1 set
Model 600 spray cooling bath
1 set
Model 600 automatic sawdust-free cutting machine
1 set
Model 600 unloading device with weighing system
1 set
*

Based on the continuous optimization of product quality and performance, the product pictures and parameters involved in this page may be different from the real products. Zhongyun reserves the right to modify the appearance design and configuration parameters of the equipment without prior notice.
